use:
This machine is mainly used for mixing wet single sand and surface sand for machine manufacturing in large and medium-sized foundries. It can also be used to mix core and no-bake sands in large foundries. And it is widely used in the mixing of powder materials in other powder engineering, such as glass, chemical, metallurgy, construction and other industries.
Features:
The roller and the rotor are optimally matched, with high sand mixing efficiency, good quality and wide application range.
Alumina wear-resistant ceramic bottom plate, tungsten carbide surfacing, greatly improves the life of wearing parts.
Fluid coupling, alloy steel gears, and lubricating controller ensure that the transmission system is stable and reliable, and can start under load.
The side discharge door is flexible in opening and reliable in operation, which completely solves the problem of sand leakage at the bottom.
The main technical parameters
Product model | Parameters Name | Disk meridian(mm) | Amount of feeding (Kg) | Productivity(t/h) | Main motor power(kw) | (r/min) |
S1318 | Rolling rotor sand mixer | ∅1800 | 650 | 15 | 22 | 36 |
S13200 | Rolling rotor sand mixer | ∅2000 | 800 | 20 | 30 | 30 |
S1320D | Rolling rotor sand mixer | ∅2000 | 800 | 20 | 30 | 30 |
S1320E | Rolling rotor sand mixer | ∅2000 | 900 | 24 | 37 | 30 |
S1322 | Rolling rotor sand mixer | ∅2240 | 1350 | 30 | 55 | 31 |
